Quick Details

  • Products Status: Stock
  • Chipset Manufacturer: NVIDIA
  • Interface Type: PCI
  • Video Memory Capacity: ≤ 64MB
  • Video Memory Type: DDR5
  • Memory Interface: 64 Bit
  • Output Interface Type: HDMI, VGA
  • Memory Clock(Mhz): 6008MHz
  • Brand Name: OEM
  • Model Number: Dash Master A5
  • Place of Origin: China (Mainland)
  • Power connector: 7*6pin
  • PCI-E Slot: 9*PCI-E *16
  • System cooler: 10*9cm
  • Power supply: 1200
  • CPU: Intel
  • Memorry: 4GB
  • Stortage: 64GB sata SSD
  • OS: Window 10 64Bit
  • Dimension: 53*32*16
  • Weight: 15kgs

Packaging & Delivery

Packaging Details 2017 Newest Dash Master ASIC A5 Bitman Antminer D3 Litecoin L3 mining machine Antminer L3 L3+ on stock
Dimension: 53*32*16cm
Carton: 64*43*27
Weight: 15kgs
Delivery Time 10-35 working days

2017 Newest Dash Master  ASIC A5 Bitman Antminer D3  Litecoin L3 mining machine Antminer  L3 L3+ on stock

Product Description

 Service Hotline

Contact:Rachel

Web:www.btscn.com

E-mail:sales33(@)btscn.com

Tel/Wechat/WhatsApp : +86 18665966327



ASIC A5 Dash x11 Miner:
Hash Rate: 30.2 GH/s {30200 MH/s ±8%}
Power Consumption: 750 W± 8% (at the wall, with 25°C ambient temp)
Chips : A5 DashMaster ASIC
Operating Temperature: 0°C to 100°C
Network Connection: Ethernet
Dimensions: 400mm(L) * 135mm(W) * 158mm(H)

Specifications of the Antminer D3 Dash are as follows:
a) Hash rate: 15 GH/s (Variation of ±5% is expected)
b) Power consumption: 1200W (at the wall, with Bitmain’s APW3 PSU, 93% efficiency, 25°C ambient temp).
c) Dimensions of the miner: 320*130*190mm
d) Hashing algorithm: X11



Antminer L3+/L3 Litecoin miner Specifications:
1. Hash Rate: 504MH/S
2. Power Consumption:800W + 7% (at the wall, with APW3 ,93% efficiency, 25C ambient temp)
3. Power Efficiency: 1.6J/MH + 10%(at the wall, with APW3 93% efficiency, 25°C ambient temp)
4. Rated Voltage: 11.60 ~13.00V
5. Chip quantity per unit: 288PCS
6. Dimensions: 352mm(L)*130mm(W)*187.5mm(H)
8. Operating Temperature: 0 °C to 40 °C
9. Network Connection: Ethernet
6. Separate power supply to control board: there is one additional 6pin PCIe connector on the IO board which must be connected to the PSU to get power. Be sure to power on the miner only after all the PCIE connectors are connected to power supply

Bitcoin Antminer S9 Miner Specifications:
1. Hash Rate: 14TH/s ±5%
2. Power Consumption: 1235W + 7% (at the wall, with APW3 ,93% efficiency, 25C ambient temp)
3. Power Efficiency: 0.098 J/GH + 7%(at the wall, with APW3 93% efficiency, 25°C ambient temp)
4. Rated Voltage: 11.60 ~13.00V
5. Chip quantity per unit: 189x BM1387
6. Dimensions: 350mm(L)*135mm(W)*158mm(H)
7. Cooling: 2x 12038 fan
8. Operating Temperature: 0 °C to 40 °C
9. Network Connection: Ethernet
10. Default Frequency: 650M

Specifications of iBelink DM11(DM22) ASIC Dash Miner :
Hash Rate: 10.8GH/s ±5%
– Power Consumption: 730 W (at the wall, with 25 °C ambient temp)
– Power Efficiency: 0.07 W/MH (at the wall, with 25 °C ambient temp)
– Number of TNB0303-FL28 chips per unit: 64
– Operating Temperature: 0 °C to 40 °C
– Network Connection: Ethernet
– Power Supply: 110V to 240V, 50Hz/60Hz, PSU 850W included
– Dimensions: 490mm(L)*350mm(W)*180mm(H)
– Weight: 22 kg



Packaging & Shipping



Company Information



Contacts

Contact:Rachel

Web:www.btscn.com

E-mail:sales33(@)btscn.com

Tel/Wechat/WhatsApp : +86 18665966327





A5 Dash Master  2017 Stock Bitman Antminer D3 15GH/S Litecoin mining machine L3  L3+ MINER ANTMINER
A5 Dash Master  2017 Stock Bitman Antminer D3 15GH/S Litecoin mining machine L3  L3+ MINER ANTMINER
A5 Dash Master  2017 Stock Bitman Antminer D3 15GH/S Litecoin mining machine L3  L3+ MINER ANTMINER
